The giant brick kiln is the heart of the production

HELUZ cihlářský průmysl v.o.s. is the largest Czech producer of brick material and is constantly improving its production. Therefore, during March and April 2021, a reconstruction of the kiln for brick products was carried out in Dolní Bukovsko. The length of the kiln is 120 m, it fires about 300 tons of bricks per day and the firing time is 20-26 hours. The kiln is in operation 24 hours a day and the kiln is always shut down after many years. That’s why the smooth running of the kiln is vital to production.

The reconstruction of the kiln included, among other things, the replacement of the side pre-burners and high-speed burners, including the connecting hoses that gas feed into the kiln. The original rubber hoses were already showing signs of many years of operation in harsh conditions. The surface of the hoses had been corroded and the hose barbs had been ripped from the end caps. This exposed the rubber inside of the hose, which was already worn and threatened to leak gas. This type of rubber hose for gas supply no longer meets the current European mandatory standards.

Unique 2-in-1 detachable gas hose

HELUZ service technicians decided to install premium MERABELL GAS PROFI hoses with valve mainly because of their superior 25-year warranty and high quality hose. These features give them the assurance of long term use without the need for replacement after regular inspections or when worn out. In long term, this compensates the higher purchase price of the hose several times over.

The MERABELL 2-in-1 hose is unique due to its detachable bayonet valve with thermal safety lock. The hose can be easily disconnected from the valve and reconnected at any time by simply turning the bayonet cap and pulling the hose out of the bayonet. This greatly simplifies and reduces the cost of service and maintenance, as it can be carried out by HELUZ company crews without the need for a professional inspection technician.

Benefits of the all stainless steel hose GAS PROFI with valve

• The hose is certified according to the ČSN EN 15266 standard (Stainless-steel pliable corrugated tubing kits in buildings for gas with an operating pressure of up to 0.5 bar) that is already mandatory in the Europe.
• The hose is protected against mechanical damage by a stainless steel braid
• It is protected against aggressive substances such as cleaning agents by a clear PVC sheathing on its surface
• The swivel ending on the side of appliance prevents the hose from twisting in the thread and possible gas leakage.
• The valve's thermal fuse automatically shuts off the gas supply when the temperature exceeds 100 °C, thus preventing the risk of explosion.
• The thermal fuse of the valve automatically closes the gas supply when the temperature exceeds 100 °C. The bayonet lock allows for very easy disconnection and connection of the gas appliance by the user, without the need to call a certified installer – e. g. when it is necessary for painting, cleaning.
• The superior 25-year warranty guarantees long-term use of the hose without the need for replacement after regular inspections or when replacing the appliance.

Project assessment

HELUZ service technicians appreciated the very short delivery time of the hoses, even though a large quantity of hoses (130 pieces) was ordered. This made it easier for the technicians to plan the actual replacement, which was also linked to the replacement of the pre-burners and burners. The complete installation of all 130 hoses was completed by two HELUZ service technicians in one working day without any difficulties.

By investing in premium MERABELL connection hoses, HELUZ has gained the certainty that the kiln will not need to be shut down due to gas connection until 2046 at the earliest.
